TOROIDAL TRANSFORMERS > AUDIO TRANSFORMER
Enlarge
Model:Toroidal Audio
Toroidal transformers ranged from 50VA - 5000VA for audio appication. Customized design welcome.
Features:

Toroidal Transformer for Audio

Scientek offers a variety of audio application Toroidal transformers for specific needs.

All are constructed to meet low mechanical noise and low leakage flux.



Brief Specifications

ü Power Range:30VA -5000VA

ü Input/Output: Customized

ü Insulation Class: UL class B. F. H. N.(Optional)

ü Isolation: 4KV (Hi-pot)



Rated Power

Dimension D*H

Weight

Temp. Rise

Approval

50VA

80mm*37mm

0.71Kg

 45℃

CE/CQC/RoHS/UL

100VA

95mm*45mm

1.24Kg

 51℃

CE/CQC/RoHS/UL

200VA

112mm*52mm

2.04Kg

 52℃

CE/CQC/RoHS/UL

250VA

118mm*53mm

3.36Kg

 53℃

CE/CQC/RoHS/UL

500VA

140mm*65mm

4.20Kg

 55℃

CE/CQC/RoHS/UL

1000VA

170mm*75mm

7.20Kg

 58℃

CE/CQC/RoHS/UL

1500VA

180mm*85mm

9.75Kg

 60℃

CE/CQC/RoHS/UL

2000VA

185mm*105mm

12.00Kg

 62℃

CE/CQC/RoHS/UL

3000VA

200mm*120mm

16.60Kg

 64℃

CE/CQC/RoHS/UL

5000VA

230mm*135mm

24.00Kg

 65℃

CE/CQC/RoHS/UL
