EI Transformer for Lighting
Scientek EI Power Transformer for Lighting is assembled in housing with epoxy to meet IP68 Water-proof Standard. It’s distinguished by its durability and low temperature rise.
Brief Specification
ü Power Range: 30VA -400VA
ü Input/Output: Customized
ü Work Circle: Customized
ü Insulation Class: UL class B. F. H. N.(Optional)
ü Isolation: 3.75KV (Hi-pot)
|
Model |
Spec. |
Power
(VA) |
Voltage
(V) |
Dimension
(mm) |
Installation Size(mm) |
Hole Dimension
(mm) |
Weigt
(kg) |
|
A |
B |
C |
D |
E |
F |
|
|
EL57 |
57*28 |
30 |
- |
81 |
53 |
53 |
72 |
42 |
4*5 |
0.72 |
|
EL66 |
66*32 |
40 |
- |
93 |
64 |
69 |
83 |
52 |
Ø5 |
1.10 |
|
66*36 |
50 |
- |
93 |
64 |
69 |
83 |
52 |
Ø5 |
1.35 |
|
EL86 |
86*38 |
80 |
- |
127 |
82 |
75 |
110 |
65 |
Ø6 |
1.85 |
|
86*42 |
100 |
- |
127 |
82 |
75 |
110 |
65 |
Ø6 |
2.35 |
|
EL96 |
96*56 |
200 |
- |
136 |
85 |
43 |
121 |
80 |
4.5*8.3 |
3.82 |
|
EL120 |
120*60 |
300 |
- |
130 |
107 |
60 |
105 |
90 |
Ø6 |
6.25 |
|
EL150 |
150*50 |
400 |
- |
156 |
120 |
85 |
130 |
95 |
Ø6 |
9.05 |
|
