Toroidal transformer for UPS & inverter
Scientek toroidal transformer for UPS & Inverter featured with high efficiency, light weight, compact size and low temperature rise.
Brief Specification
ü Power Range: 500VA -10000VA
ü Phase: Single
ü Input/Output: Customized
ü Insulation Class: UL class B. F. H. N.(Optional)
ü Isolation: 4KV (Hi-pot)
|
Rated Power |
Dimension D*H |
Weight |
Temp. Rise |
Approval |
|
500VA |
145mm*65mm |
5.5Kg |
52℃ |
CE/CQC/RoHS/UL |
|
1000VA |
175mm*85mm |
8.5Kg |
54℃ |
CE/CQC/RoHS/UL |
|
2000VA |
210mm*90mm |
14.7Kg |
55℃ |
CE/CQC/RoHS/UL |
|
2500VA |
210mm*100mm |
16.7Kg |
56℃ |
CE/CQC/RoHS/UL |
|
3000VA |
215mm*105mm |
17.7Kg |
57℃ |
CE/CQC/RoHS/UL |
|
3500VA |
230mm*115mm |
21.8Kg |
58℃ |
CE/CQC/RoHS/UL |
|
5000VA |
290mm*115mm |
30.0Kg |
69℃ |
CE/CQC/RoHS/UL |
|
7000VA |
330mm*115mm |
35.0Kg |
62℃ |
CE/CQC/RoHS/UL |
|
10000VA |
360mm*115mm |
45.0Kg |
65℃ |
CE/CQC/RoHS/UL |
|
