Toroidal Transformer for Wind Power
Scientek Toroidal Transformer for Wind power system featured with High efficiency,
low inrush current and low temperature rise characteristics which are popular in the market.
The transformer efficiency is up to 98%.
Brief Specification
ü Power Range:1000VA - 30KVA
ü Phase: Single / Three phase
ü Input: On request
ü Output: On request
ü Insulation Class: UL class B. F. H. N.(Optional)
ü Isolation: 4KV (Hi-pot)
|
Rated Power |
Efficiency |
Dimension D*H |
Weight |
Approval |
|
1000VA |
97.0% |
175mm*85mm |
9.10Kg |
CE/CQC |
|
1500VA |
97.0% |
195mm*85mm |
11.5Kg |
CE/CQC |
|
2000VA |
97.5% |
210mm*90mm |
14.7Kg |
CE/CQC |
|
2500VA |
97.5% |
210mm*100mm |
16.7Kg |
CE/CQC |
|
3000VA |
97.5% |
215mm*105mm |
17.7Kg |
CE/CQC |
|
3500VA |
97.7% |
230mm*115mm |
21.8Kg |
CE/CQC |
|
4800VA |
98.0% |
245mm*150mm |
31.2Kg |
CE/CQC |
|
5200VA |
98.3% |
245mm*150mm |
31.3Kg |
CE/CQC |
|
